| [{"name" |
-
•
"Image Sensor","values":["1/2.8" CMOS"]},{"name":"Max. Resolution","values":["1920 (H) × 1080 (V)"]},{"name":"ROM","values":["128 MB"]},{"name":"RAM","values":["128 MB"]},{"name":"Scanning System","values":["Progressive"]},{"name":"Electronic Shutter Speed","values":["Auto/Manual 1/3 s–1/100,000 s :"]},{"name":"Min. Illumination","values":["0.002 lux@F1.6 (Color, 30 IRE) / 0.0002 lux@F1.6 (B/W, 30 IRE) / 0 lux (Illuminator on)"]},{"name":"S/N Ratio","values":[">56 dB"]},{"name":"Illumination Distance","values":["30 m (98.43 ft) (IR), 30 m (98.43 ft) (Warm light)"]},{"name":"Illuminator On/Off Control","values":["Auto; Manual"]},{"name":"Illuminator Number","values":["1 (IR LED); 1 (Warm light)"]},{"name":"Lens Type","values":["Fixed-focal"]},{"name":"Lens Mount","values":["M12"]},{"name":"Focal Length","values":["2.8 mm"]},{"name":"Max. Aperture","values":["F1.6"]},{"name":"Field of View","values":["2.8 mm: H: 107°; V: 56°; D: 127°"]},{"name":"Iris Control","values":["Fixed"]},{"name":"Close Focus Distance","values":["2.8 mm: 0.7 m"]},{"name":"IVS (Perimeter Protection)","values":["Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human)"]},{"name":"Smart Search","values":["Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos"]},{"name":"Video Compression","values":["H.264H; H.265; H.264; H.264B; MJPEG (Only supported by the sub stream)"]},{"name":"Smart Codec","values":["Smart H.265+; Smart H.264+"]},{"name":"Video Frame Rate","values":["Main stream: 1920 × 1080@ (1–25/30 fps) / Sub stream: 704 × 576@ (1–25 fps)/704 × 480@ (1–30 fps) / *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity"]},{"name":"Stream Capability","values":["2 streams"]},{"name":"Resolution","values":["1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)"]},{"name":"Bit Rate Control","values":["CBR/VBR"]},{"name":"Video Bit Rate","values":["H.264: 32 kbps–6144 kbps; / H.265: 12 kbps–6144 kbps"]},{"name":"Day/Night","values":["Auto (ICR)/Color/B/W"]},{"name":"BLC","values":["Yes"]},{"name":"HLC","values":["Yes"]},{"name":"WDR","values":["120 dB"]},{"name":"White Balance","values":["Auto; natural; street lamp; outdoor; manual; regional custom"]},{"name":"Gain Control","values":["Auto; Manual"]},{"name":"Noise Reduction","values":["3D NR"]},{"name":"Motion Detection","values":["OFF/ON (4 areas, rectangular)"]},{"name":"Region of Interest (RoI)","values":["Yes (4 areas)"]},{"name":"Smart Illumination","values":["Yes"]},{"name":"Image Rotation","values":["0°/90°/180°/270° (Support with 1080p resolution and lower)"]},{"name":"Mirror","values":["Yes"]},{"name":"Privacy Masking","values":["4 areas"]},{"name":"Built-in MIC","values":["Yes"]},{"name":"Audio Compression","values":["G.711a; G.711Mu; PCM; G.726"]},{"name":"Alarm Event","values":["No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; SMD; voltage detection; security exception"]},{"name":"Network Port","values":["RJ-45 (10/100 Base-T)"]},{"name":"SDK and API","values":["Yes"]},{"name":"Network Protocol","values":["IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP"]},{"name":"Interoperability","values":["ONVIF (Profile S/Profile T); CGI; P2P; Milestone"]},{"name":"User/Host","values":["6 (Total bandwidth: 36 M)"]},{"name":"Storage","values":["FTP; SFTP; Micro SD card (support max. 256 GB)"]},{"name":"Browser","values":["IE; Chrome; Firefox"]},{"name":"Management Software","values":["DSS; DMSS"]},{"name":"Mobile Client","values":["iOS; Android"]},{"name":"Cyber Security","values":["Configuration encryption; Trusted execution; Digest; Security logs; WSSE; Account lockout; syslog; Video encryption; 802.1x; IP/MAC filtering; HTTPS; Trusted upgrade; Trusted boot; Generation and importing of X.509 certification"]},{"name":"Certifications","values":["CE-LVD: EN 62368-1 / CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU / FCC: 47 CFR FCC Part 15, Subpart B"]},{"name":"Power Supply","values":["12 VDC/PoE (802.3af)"]},{"name":"Power Consumption","values":["Basic: 1.6 W (12 VDC); 1.9 W (PoE); Max. (H.265 + intelligence + WDR + warm light): 3.8 W (12 VDC); 4.4 W (PoE)"]},{"name":"Operating Temperature","values":["–40 °C to +60 °C"]},{"name":"Operating Humidity","values":["≤95%"]},{"name":"Storage Temperature","values":["–40 °C to +60 °C"]},{"name":"Protection","values":["IP67"]},{"name":"Casing Material","values":["Metal"]},{"name":"Product Dimensions","values":["166.2 mm × 70 mm × 70 mm (L × W × H)"]},{"name":"Net Weight","values":["0.48 kg"]},{"name":"Gross Weight","values":["0.59 kg"]},{"name":"","values":["2-MP 1/2.8" CMOS image sensor, low luminance, and high definition image"]},{"name":"","values":["Outputs max. 2 MP (1920 × 1080)@25/30 fps"]},{"name":"","values":["H.265 codec, high compression rate, ultra-low bit rate"]},{"name":"Built-in warm light/IR LED, the max. illumination distance is","values":["30 m and the max. warm light distance is 30 m"]},{"name":"","values":["ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments"]},{"name":"Rotation mode, WDR,","values":["3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes"]},{"name":"Intelligent monitoring","values":["Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human)"]},{"name":"","values":["Supports max. 256 G Micro SD card; built in MIC"]},{"name":"","values":["12 VDC/PoE power supply, easy for installation"]},{"name":"","values":["IP67 protection"]},{"name":"SMD","values":["Plus"]}]
|
