| [{"name" |
-
•
"Max. Resolution","values":["2560 (H) × 1440 (V)"]},{"name":"ROM","values":["128 MB"]},{"name":"RAM","values":["512 MB"]},{"name":"Electronic Shutter Speed","values":["1/1 s–1/30,000 s"]},{"name":"Scanning System","values":["Progressive"]},{"name":"Min. Illumination","values":["Color: 0.005 lux@F1.6 / B/W: 0.0005 lux@F1.6 / 0 lux (IR light on)"]},{"name":"Illumination Distance","values":["50 m (164.04 ft) (IR) / 30 m (98.43 ft) (Warm light)"]},{"name":"Illuminator On/Off Control","values":["Zoom Prio / Manual / Auto / Off"]},{"name":"Illuminator Number","values":["2 (IR) / 2 (Warm light) / 1 (Red light) / 1 (Blue light)"]},{"name":"Focal Length","values":["2.7 mm–13.5 mm"]},{"name":"Max. Aperture","values":["F1.6–F3.0"]},{"name":"Field of View","values":["H: 94.9°–30.1° / V: 51°–17.1° / D: 112.3°–34.6°"]},{"name":"Optical Zoom","values":["5×"]},{"name":"Focus Control","values":["Auto / semi-auto / manual"]},{"name":"Close Focus Distance","values":["1.5 m"]},{"name":"Iris Control","values":["Fixed"]},{"name":"Pan/Tilt Range","values":["Pan: 0° to 355° / Tilt: –15° to +90°"]},{"name":"Manual Control Speed","values":["Pan: 0.1°/s–36°/s / Tilt: 0.1°/s–25.8°/s"]},{"name":"Preset Speed","values":["Pan: 35.7°/s / Tilt: 27.1°/s"]},{"name":"Preset","values":["300"]},{"name":"Power-off Memory","values":["Yes"]},{"name":"Idle Motion","values":["Preset"]},{"name":"IVS (Perimeter Protection)","values":["Tripwire / intrusion / crossing fence detection / loitering detection / abandoned/missing object / fast moving / parking detection / people gathering / vehicle/human alarm classification / linkage tracking"]},{"name":"Face Detection","values":["Supports face detection / snapshot / face enhancement / Supports face cutout: Face, one-inch photo / Capturing strategies include real-time capturing and quality first"]},{"name":"Auto Tracking Lite","values":["Yes"]},{"name":"SMD","values":["Yes"]},{"name":"Light Warning","values":["Red and blue light warning / Flash duration: 5 s–30 s / Flash frequency: high / medium / low"]},{"name":"Sound Warning","values":["Offers 11 types of sound alarms / supports importing up to 10 custom sound alarms. The sound alarm can be set to play 1 to 10 times"]},{"name":"Video Compression","values":["H.264H / H.264B /Smart H.265+ / H.264 / H.265 /MJPEG(Sub Stream) / Smart H.264+"]},{"name":"Streaming Capability","values":["3 streams"]},{"name":"Resolution","values":["4M (2560 × 1440) / 3M (2304 × 1296) / 1080p (1920 × 1080) / 1.3M (1280 × 960) / 720p(1280 × 720) / D1 (704 × 576); VGA (640 × 480) / CIF (352 × 288)"]},{"name":"Video Frame Rate","values":["Main stream: 4M/3M/1080p/1.3M/720p @(1–25/30 fps) / Sub stream 1: D1/CIF/VGA@ (1–25/30 fps) / Sub stream 2: 720p @(1–25/30 fps)"]},{"name":"Bit Rate Control","values":["CBR/VBR"]},{"name":"Video Bit Rate","values":["H.264: 96 kbps–14848 kbps / H.265: 38 kbps–8960 kbps"]},{"name":"Day/Night","values":["Auto (ICR) / Color / B/W"]},{"name":"BLC","values":["Yes"]},{"name":"WDR","values":["120 dB"]},{"name":"HLC","values":["Yes"]},{"name":"White Balance","values":["Auto / indoor / outdoor / tracking / manual / sodium lamp / natural light / street lamp"]},{"name":"Gain Control","values":["Auto / manual"]},{"name":"Noise Reduction","values":["2D NR / 3D NR"]},{"name":"Motion Detection","values":["Yes"]},{"name":"Region of Interest (RoI)","values":["Yes"]},{"name":"Image Stabilization","values":["Electronic (EIS)"]},{"name":"Defog","values":["Electronic"]},{"name":"Digital Zoom","values":["16×"]},{"name":"Image Rotation","values":["180°"]},{"name":"S/N Ratio","values":["≥55 dB"]},{"name":"Audio Compression","values":["G.711a / G.711Mu / G.726 / MPEG2-Layer2 / G722.1 / PCM"]},{"name":"Network Port","values":["RJ-45 (10/100 Base-T)"]},{"name":"Network Protocol","values":["FTP / RTMP / IPv6 / Bonjour / IPv4 / DNS / RTCP / PPPoE / NTP / /RTP / 802.1x / HTTPS / SNMP / TCP/IP / DDNS / UPnP / NFS / ICMP / UDP / IGMP / SMB / HTTP / SSL / DHCP / SMTP / Qos / RTSP / ARP"]},{"name":"Interoperability","values":["CGI / SDK / ONVIF (Profile S&G&T) / P2P"]},{"name":"Streaming Method","values":["Unicast/Multicast"]},{"name":"User/Host","values":["20 (total bandwidth: 64 M)"]},{"name":"Storage","values":["FTP/SFTP / Micro SD card (512 GB) / NAS"]},{"name":"Browser","values":["IE 9 and later versions / Chrome 41 and later versions / Firefox 50 and later versions / Safari 10 and later versions"]},{"name":"Management Software","values":["DMSS / DSS Pro"]},{"name":"Mobile Client","values":["iOS / Android"]},{"name":"Certifications","values":["CE: EN55032/EN55024/EN50130-4 / FCC: Part15 subpartB, ANSI C63.4-2014"]},{"name":"Audio Input","values":["1 channel (LINE IN / bare wire / built-in mic (mutually exclusive))"]},{"name":"Audio Output","values":["1 channel (LINE OUT / bare wire / built-in speaker (mutually exclusive))"]},{"name":"Alarm Linkage","values":["Capture / recording / send email / preset / alarm digital input / audio / warning light"]},{"name":"Alarm Event","values":["Motion/tampering detection / audio detection / network disconnection detection / IP conflict detection / memory card state detection / memory space detection"]},{"name":"Alarm I/O","values":["1/1"]},{"name":"Audio I/O","values":["1/1"]},{"name":"Power Supply","values":["12 VDC / 2 A ± 10% / PoE+ (802.3at)"]},{"name":"Power Consumption","values":["Basic: 4.5 W / Max.: 15 W (illuminator + PTZ + speaker + heating glass)"]},{"name":"Operating Temperature","values":["–30 °C to +60 °C"]},{"name":"Operating Humidity","values":["≤95%"]},{"name":"Protection","values":["IP66 / TVS 6000 V lightning proof / surge protection / voltage transient protection"]},{"name":"Product Dimensions","values":["142.6 mm × 140 mm × 236.1 mm"]},{"name":"Net Weight","values":["1.5 kg"]},{"name":"Gross Weight","values":["2.1 kg"]},{"name":"","values":["1/2.8" 4Megapixel CMOS"]},{"name":"","values":["5x optical zoom"]},{"name":"Max.","values":["25/30fps@4M"]},{"name":"IR distance up to","values":["50 m"]},{"name":"Warm light illumination distance up to","values":["30 m"]},{"name":"SMD","values":["3.0"]},{"name":"","values":["Perimeter protection"]},{"name":"","values":["Face detection"]},{"name":"Alarm","values":["1 in / 1 out / Audio : 1 in / 1 out"]},{"name":"","values":["Built-in Mic and Speaker for Two-way Talk"]},{"name":"","values":["12 VDC/PoE power supply"]},{"name":"","values":["IP66"]},{"name":"","values":["Sound and light alarm (red and blue lights)"]}]
|
