| [{"name" |
-
•
"Switching Capacity","values":["8.8 Gbps"]},{"name":"Packet Forwarding Rate","values":["6.55 Mpps"]},{"name":"Description of Function Slots","values":["Port 1-24: 24 × RJ-45 10/100 Mbps (PoE); Port 25-26: 2 × RJ-45 10/100/1000 Mbps (combo); Port 25-26: 2 × SFP 1000 Mbps (combo)"]},{"name":"PoE Power","values":["Port 1-2 ≤ 90 W, Port 3-24 ≤ 30 W, total ≤ 240 W"]},{"name":"Layer","values":["Layer 2"]},{"name":"Operating Temperature","values":["–10 °C to +55 °C (+14 °F to +131 °F)"]},{"name":"Operating Humidity","values":["5% –95% (RH), non-condensing"]},{"name":"Power Supply","values":["Built-in power supply: 100–240 VAC, 47–63 Hz, max 4 A"]},{"name":"Power Consumption","values":["Idling: ≤8.5 W ; Full load: 265 W"]},{"name":"Statics Protection","values":["Air discharge: 8 kV; Contact discharge: 6 kV"]},{"name":"Lightning Protection","values":["Common mode: 4 kV; Differential mode: 2 kV"]},{"name":"Net Weight","values":["2.47 kg (5.43 lb)"]},{"name":"Product Dimensions","values":["440 mm × 220 mm × 44 mm (17.32" × 8.66" × 1.73") (L × W × H)"]},{"name":"PoE","values":["Yes"]},{"name":"Ethernet Port","values":["24"]},{"name":"Reset Button","values":["1"]},{"name":"Storage Temperature","values":["–40 °C to +70 °C (–40 °F to +158 °F)"]},{"name":"Storage Humidity","values":["5%–95% (RH), non-condensing"]},{"name":"MTBF","values":["64.20 years"]},{"name":"Packet Buffer Size","values":["4 Mbit"]},{"name":"Jumbo Frame","values":["15K Byte"]},{"name":"MAC Table Size","values":["8K"]},{"name":"VLAN Number","values":["32"]},{"name":"Communication Standard","values":["IEEE802.3; IEEE802.3u; IEEE802.3x; IEEE802.3ab; IEEE802.3z"]},{"name":"PoE Protocol","values":["IEEE802.3af; IEEE802.3at; Hi-PoE; IEEE802.3bt"]},{"name":"PoE Power Consumption Management","values":["Yes"]},{"name":"PoE Pin Assignment","values":["1,2,4,5ï¼V+ï¼,3,6,7,8ï¼V-ï¼"]},{"name":"Long Distance PoE Transmission","values":["Yes"]},{"name":"VLAN Function","values":["Port-based VLAN"]},{"name":"IEEE 802.3x Flow Control","values":["Yes"]},{"name":"DHCP Function","values":["DHCP Client"]},{"name":"Equipment Management","values":["Web management; App management"]},{"name":"Gross Weight","values":["3.12 kg (6.86 lb)"]},{"name":"Packaging Dimensions","values":["540 mm × 342 mm × 90 mm (21.26" × 13.46" × 3.54") (L × W × H)"]},{"name":"Casing Material","values":["Sheet metal"]},{"name":"Installation","values":["Desktop mount; rack mount"]},{"name":"Certifications","values":["CE"]},{"name":"Packing List","values":["Quick Start Guide × 1; Legal and Regulatory Information × 1; Power cord × 1; Rack-mount kit × 1"]},{"name":"","values":["Meets the requirements of IEEE802.3,IEEE802.3u,IEEE802.3x, IEEE802.3ab,IEEE802.3z standards."]},{"name":"","values":["Meets the requirements of IEEE802.3af, IEEE802.3at, Hi-PoE, and IEEE802.3bt power supply standards."]},{"name":"","values":["Manages PoE power consumption and PoE power on/off. Supports Intelligent PoE."]},{"name":"","values":["A wide operating temperature range and a full metal casing that is fully-enclosed and dust-proof."]}]
|
