Kuwes CAT5E UTP Pure Copper Outdoor 100m Black

€63.00

Type: Cat5eCable Type: UTPConductor: Pure CopperEnvironment: OutdoorLength: 100mColour: Black

Add To Wishlist Add To Compare

Product Details

SKU : 25981
Stock : Available

Guaranteed Safe Checkout

Hotline Order:

Mon - Fri: 07:00 am - 05:30 pm

(+357) 22 261 615

Conductor:Solid Bare copper (1 x AWG24)Insulation :HDPEMin. Avg. Thickness: 0.178 mm;Min. Thickness: 0.153 mmColor Code:Pair 1: Blue & White/Blue;Pair 2: Orange & White/OrangePair 3: Green & White/Green;Pair 4: Brown & White/BrownJacket:LDPEMin. Avg. Thickness: 0.585 mm;Min. Thickness: 0.458 mmApproximate O.D.: 5.2 mm +/- 0.3mmElectric Requirements:(Cable length: 100M)Characteristic Impedance(Zo): 85～115Ω (1～100 MHz)Other Requirements: (dB/100M)DC. Resistance Capacitance Unbalance: 5％Pair-to-Ground Capacitance Unbalance: 330 pF/100M MaxConductor Resistance: 9.38Ω/ 100M 20℃ MaxMutual Capacitance: 5.6 nF/m MaxSpark Test: 2.5KV

Min. Avg. Thickness	• 0.178 mm;
Min. Thickness	• 0.153 mm
Pair 1	• Blue & White/Blue;
Pair 2	• Orange & White/Orange
Pair 3	• Green & White/Green;
Pair 4	• Brown & White/Brown
	• LDPE
Min. Avg. Thickness	• 0.585 mm;
Min. Thickness	• 0.458 mm
Approximate O.D.	• 5.2 mm +/- 0.3mm
Characteristic Impedance(Zo)	• 85～115Î© (1～100 MHz)
Other Requirements	• (dB/100M)
DC. Resistance Capacitance Unbalance	• 5％
Pair-to-Ground Capacitance Unbalance	• 330 pF/100M Max
Conductor Resistance	• 9.38Î©/ 100M 20℃ Max
Mutual Capacitance	• 5.6 nF/m Max
Spark Test	• 2.5KV

Datasheet
