Kuwes CAT5E UTP Pure Copper Outdoor 305m Black
Product Thumbnail

Kuwes CAT5E UTP Pure Copper Outdoor 305m Black

€137.00

Type: Cat5eCable Type: UTPConductor: Pure CopperEnvironment: OutdoorLength: 305mColour: Black

Add To Wishlist Add To Compare

Product Details

  • SKU : 25983
  • Stock : Available

Guaranteed Safe Checkout

Hotline Order:
Mon - Fri: 07:00 am - 05:30 pm
(+357) 22 261 615

Conductor:Solid Bare copper (1 x AWG24 0.45MM BC)Insulation :HDPEMin. Avg. Thickness: 0.175 mm;Min. Thickness: 0.153 mmColor Code:Pair 1: Blue & White/Blue;Pair 2: Orange & White/OrangePair 3: Green & White/Green;Pair 4: Brown & White/BrownJacket:LDPEMin. Avg. Thickness: 0.585 mm;Min. Thickness: 0.458 mmApproximate O.D.: 4.75 mm +/- 0.3mmElectric Requirements:(Cable length: 100M)Characteristic Impedance(Zo): 85～115Ω (1～100 MHz)Other Requirements: (dB/100M)DC. Resistance Capacitance Unbalance: 5％Pair-to-Ground Capacitance Unbalance: 330 pF/100M MaxConductor Resistance: 9.38Ω/ 100M  20℃ MaxMutual Capacitance: 5.6 nF/m MaxSpark Test: 2.5KV

Min. Avg. Thickness
  • • 0.175 mm;
Min. Thickness
  • • 0.153 mm
Pair 1
  • • Blue & White/Blue;
Pair 2
  • • Orange & White/Orange
Pair 3
  • • Green & White/Green;
Pair 4
  • • Brown & White/Brown
  • • LDPE
Min. Avg. Thickness
  • • 0.585 mm;
Min. Thickness
  • • 0.458 mm
Approximate O.D.
  • • 4.75 mm +/- 0.3mm
Characteristic Impedance(Zo)
  • • 85～115Ω (1～100 MHz)
Other Requirements
  • • (dB/100M)
DC. Resistance Capacitance Unbalance
  • • 5％
Pair-to-Ground Capacitance Unbalance
  • • 330 pF/100M Max
Conductor Resistance
  • • 9.38Ω/ 100M 20℃ Max
Mutual Capacitance
  • • 5.6 nF/m Max
Spark Test
  • • 2.5KV
