| [{"name" |
-
•
"Image Sensor","values":["Dual 1/2.7" CMOS"]},{"name":"Max. Resolution","values":["4096 (H) × 1860 (V)"]},{"name":"ROM","values":["128 MB"]},{"name":"RAM","values":["1 GB"]},{"name":"Scanning System","values":["Progressive"]},{"name":"Electronic Shutter Speed","values":["Auto/Manual 1/3 s–1/100,000 s"]},{"name":"Min. Illumination","values":["0.005 lux@F1.4 (Color, 30 IRE) / 0.0005 lux@F1.4 (B/W, 30 IRE) / 0 lux (Illuminator on)"]},{"name":"S/N Ratio","values":[">56 dB"]},{"name":"Illumination Distance","values":["Up to 25 m (IR LED) / Up to 20 m (Warm light)"]},{"name":"Illuminator On/Off Control","values":["Auto; Manual"]},{"name":"Illuminator Number","values":["2 (IR LED); 2 (Warm light)"]},{"name":"Lens Type","values":["Fixed-focal"]},{"name":"Lens Mount","values":["M12"]},{"name":"Focal Length","values":["2.8 mm"]},{"name":"Field of View","values":["Horizontal: 180°; Vertical: 86°"]},{"name":"Max. Aperture","values":["F1.4"]},{"name":"Iris Control","values":["Fixed"]},{"name":"Close Focus Distance","values":["0.8 m"]},{"name":"IVS (Perimeter Protection)","values":["Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human)"]},{"name":"SMD","values":["SMD 4.0"]},{"name":"Quick Pick","values":["With AI NVR, quickly pick up the human/vehicle targets that users are interested in from SMD events."]},{"name":"Smart Search","values":["Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos."]},{"name":"EPTZ","values":["Enlarge and track the targets of intelligent alarms"]},{"name":"Video Compression","values":["H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)"]},{"name":"Smart Codec","values":["Smart H.265+ / Smart H.264+"]},{"name":"AI Coding","values":["AI H.265 / AI H.264"]},{"name":"Video Frame Rate","values":["Main stream: 4096 × 1860@(1–20 fps ) / Sub stream: 1200 × 530@(1–20 fps) / Third stream: 1920 × 860@(1–20 fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity."]},{"name":"Stream Capability","values":["3 streams"]},{"name":"Resolution","values":["4096 × 1860; 3632 × 1632; 3040 × 1368; 1200 × 530; 1920 × 860; 960 × 432"]},{"name":"Bit Rate Control","values":["CBR/VBR"]},{"name":"Video Bit Rate","values":["H.264: 6 kbps –16384 kbps / H.265: 6 kbps –16384 kbps"]},{"name":"Day/Night","values":["Auto(ICR)/Color/B/W"]},{"name":"BLC","values":["Yes"]},{"name":"HLC","values":["Yes"]},{"name":"WDR","values":["120 dB"]},{"name":"Scene Self-adaptation (SSA)","values":["Yes"]},{"name":"White Balance","values":["Auto; natural; street lamp; outdoor; manual; regional custom"]},{"name":"Gain Control","values":["Auto"]},{"name":"Noise Reduction","values":["3D NR"]},{"name":"Motion Detection","values":["OFF/ON (4 areas, rectangular)"]},{"name":"Region of Interest (RoI)","values":["Yes (4 areas)"]},{"name":"Privacy Masking","values":["4 areas"]},{"name":"Defog","values":["Yes"]},{"name":"Built-in MIC","values":["Yes, built-in dual Mic"]},{"name":"Built-in Speaker","values":["Yes, built-in speaker"]},{"name":"Audio Compression","values":["G.711a; G.711Mu; PCM; G.726; G.723"]},{"name":"Alarm Event","values":["No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; scene chaging; audio detection; voltage detection; external alrm; SMD; security exception"]},{"name":"Network Port","values":["RJ-45 (10/100 Base-T)"]},{"name":"SDK and API","values":["Yes"]},{"name":"Cyber Security","values":["Video encryption; Firmware encryption; Configuration encryption; Digest; WSSE; Account lockout; Security logs; IP/MAC filtering; Generation and importing of X.509 certification; syslog; HTTPS; 802.1x; Trusted boot; Trusted execution; Trusted upgrade"]},{"name":"Network Protocol","values":["IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; P2P"]},{"name":"Interoperability","values":["ONVIF (Profile S/Profile G/Profile T); CGI"]},{"name":"User/Host","values":["20 (Total bandwidth: 64 M)"]},{"name":"Storage","values":["FTP; SFTP; Micro SD card (support max. 256 GB); NAS"]},{"name":"Browser","values":["IE: IE 8 and later"]},{"name":"Chrome","values":["Firefox"]},{"name":"Management Software","values":["Smart PSS Lite; DSS; DMSS"]},{"name":"Mobile Client","values":["iOS; Android"]},{"name":"Certifications","values":["CE-LVD: EN62368-1 / CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU"]},{"name":"Audio Input","values":["1 channel (RCA port)"]},{"name":"Audio Output","values":["1 channel (RCA port)"]},{"name":"Alarm Input","values":["1 channel in: wet contact, 5 mA 3 V–5 VDC"]},{"name":"Alarm Output","values":["1 channel out: wet contact, 300 mA 12 VDC"]},{"name":"Power Supply","values":["12 VDC (±30%); PoE (802.3af)"]},{"name":"Power Consumption","values":["Basic: 3.4 W (12 VDC); 3.8 W (PoE)"]},{"name":"Max. (H.265+WDR+ warm light+siren and light active deterrence + intelligence on)","values":["9 W (12 VDC); 10.3 W (PoE)"]},{"name":"Operating Temperature","values":["–40 °C to +60 °C"]},{"name":"Operating Humidity","values":["≤95%"]},{"name":"Storage Temperature","values":["–40 °C to +60 °C"]},{"name":"Protection","values":["IP67"]},{"name":"Casing","values":["Metal"]},{"name":"Product Dimensions","values":["183.1 mm × 99.0 mm × 78.0 mm (L × W × H)"]},{"name":"Net Weight","values":["695 g"]},{"name":"Gross Weight","values":["870 g"]},{"name":"","values":["Outputs 180° wide angle splicing image"]},{"name":"","values":["Outputs max. 8 MP (4096 × 1860)@20 fps"]},{"name":"","values":["H.265 codec, high compression rate, ultra-low bit rate"]},{"name":"Built-in IR LED and warm light, the max. IR illumination distance is","values":["25 m and warm light distance is 20 m"]},{"name":"","values":["ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments"]},{"name":"WDR,","values":["3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes"]},{"name":"Alarm","values":["1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built in dual Mic; built in speaker, support two-way talk"]},{"name":"","values":["12 VDC/PoE power supply, easy for installation"]},{"name":"","values":["IP67 protection"]},{"name":"","values":["Sound and light alarm (red and blue lights)"]},{"name":"SMD","values":["4.0"]},{"name":"","values":["One-tap arming/disarming through alarm input"]}]
|
