Kuwes CAT5E UTP Pure Copper Indoor 100m Grey
Product Thumbnail

Kuwes CAT5E UTP Pure Copper Indoor 100m Grey

€57.00

Type: Cat5eCable Type: UTPConductor: Pure CopperEnvironment: IndoorLength: 100mColour: Grey

Add To Wishlist Add To Compare

Product Details

  • SKU : 25980
  • Stock : Out of Stock

Guaranteed Safe Checkout

Hotline Order:
Mon - Fri: 07:00 am - 05:30 pm
(+357) 22 261 615

Conductor:Solid Bare copper (1 x AWG24)Insulation :HDPEMin. Avg. Thickness: 0.178 mmMin. Thickness: 0.153 mmColor Code:Pair 1: Blue & White/BluePair 2: Orange & White/OrangePair 3: Green & White/GreenPair 4: Brown & White/BrownJacket:75°C PVC CompoundMin. Avg. Thickness: 0.585 mmMin. Thickness: 0.458 mmApproximate O.D.: 5.2 mm +/- 0.3mmElectric Requirements:(Cable length: 100M)Characteristic Impedance(Zo): 85～115Ω (1～350MHz)Other Requirements: (dB/100M)DC. Resistance Capacitance Unbalance: 5％Pair-to-Ground Capacitance Unbalance: 330 pF/100M MaxConductor Resistance: 9.38Ω/ 100M  20°C MaxMutual Capacitance: 5.6 nF/m MaxSpark Test: 2.5KVNominal Velocity of Propagation (NVP): 69 %

Min. Avg. Thickness
  • • 0.178 mm
Min. Thickness
  • • 0.153 mm
Pair 1
  • • Blue & White/Blue
Pair 2
  • • Orange & White/Orange
Pair 3
  • • Green & White/Green
Pair 4
  • • Brown & White/Brown
Min. Avg. Thickness
  • • 0.585 mm
Min. Thickness
  • • 0.458 mm
Approximate O.D.
  • • 5.2 mm +/- 0.3mm
Characteristic Impedance(Zo)
  • • 85～115Ω (1～350MHz)
Other Requirements
  • • (dB/100M)
DC. Resistance Capacitance Unbalance
  • • 5％
Pair-to-Ground Capacitance Unbalance
  • • 330 pF/100M Max
Conductor Resistance
  • • 9.38Ω/ 100M 20°C Max
Mutual Capacitance
  • • 5.6 nF/m Max
Spark Test
  • • 2.5KV
Nominal Velocity of Propagation (NVP)
  • • 69 %
